NSIT Exclusive · Private label
Engineered to outperform. Priced to save.
NSHP — North Shore High Performance — is our own line of solid-carbide end mills: engineered in the USA, precision-crafted in Poland, and stocked right here at NSIT. Aggressive feeds and speeds, superior surface finish, and longer tool life, at introductory pricing dramatically below the big catalog brands.
Aggressive feeds & speeds
Superior surface finish
Maximum tool life
3-Flute · 45° Helix
Built for aluminum
High-helix, high-shear geometry for aluminum and non-ferrous — fast material removal with a clean, bright finish.
4–8 Flute · Variable Helix & Index
Chatter-free in steels & exotics
Variable helix and index break up harmonics for stable, chatter-free cutting in steels, stainless, and high-temp alloys.
Stock program, priced by diameter
292 in-stock options · 1/8″ – 1″ · 3–8 flute
| Diameter | Flutes | End styles | Corner radius | Your price |
|---|---|---|---|---|
| 1/8″.125 | 4 · 5 | SQ | .015–.030″ | from$15 |
| 5/32″.156 | 4 | SQBN | .015″ | from$25 |
| 3/16″.188 | 4 · 5 | SQ | .015–.030″ | from$21 |
| 7/32″.219 | 4 | SQ | .015″ | from$37 |
| 1/4″.250 | 3 · 4 · 5 · 6 | SQBN | .015–.090″ | from$22 |
| 9/32″.281 | 4 | SQ | .015–.030″ | from$42 |
| 5/16″.313 | 4 · 5 | SQBN | .015–.090″ | from$35 |
| 11/32″.344 | 4 | SQ | .030″ | from$49 |
| 3/8″.375 | 4 · 5 · 6 | SQBN | .015–.120″ | from$40 |
| 1/2″.500 | 3 · 4 · 5 · 6 | SQBN | .015–.190″ | from$70 |
| 5/8″.625 | 4 · 5 · 6 | SQBN | .015–.190″ | from$115 |
| 3/4″.750 | 4 · 5 · 6 · 8 | SQBN | .015–.250″ | from$169 |
| 1″1.000 | 4 | SQ | .030″ | from$347 |
Prices in USD, each. Square (SQ), Ball Nose (BN) & Corner Radius (CR) profiles available in multiple lengths of cut, coatings & substrates. Diameters also available in metric. Prices subject to change.
🇺🇸 Engineered in the USA
✦
Precision crafted in Poland 🇵🇱
Try NSHP on your next job.
292 stocked options from 1/8″ to 1″, priced by diameter — squares, ball noses, and corner radii in multiple lengths, coatings, and substrates. Order direct, or tell us the size and we'll confirm availability and pricing.
AI Tool Finder
Describe your application → get the right NSHP end mill
Describe your material, operation, and diameter
1/2 inch 4-flute roughing 4140 pre-hard steel
1/2 inch 5-flute finishing 17-4 stainless
1/2 inch 3-flute aluminum 6061 high RPM
1/2 inch 5-flute Ti-6Al-4V titanium flood coolant
3/4 inch 4-flute corner radius profiling steel
1/2 inch 5-flute ball nose 3D contouring
○
Parsing your application...○
Matching NSHP catalog...○
Generating recommendations...AI service unavailable — call 978·356·2500 or use the Speed & Feed Calculator below.
Results
NSHP application data · Estimates only — always verify in cut · 978·356·2500
Cutting Parameter Calculators
Validated application data
How ball nose parameters work
ADOC < 50% of diameter: Tool only cuts on part of its radius. Calculate effective cutting diameter (De) and use it for RPM and chip load — do not use actual D.
ADOC ≥ 50% of diameter: Use standard slotting speeds & feeds with actual D. Apply long-reach projection correction if gauge length exceeds 2.5×D.
De = 2×√(R²−(R−ADOC)²) · IPTadj = (D×IPTslot)/De · RPM = (SFM×3.82)/De · h = ae²/(8R)
Enter ADOC above to calculate adjusted parameters →
